Coils
Coils
STULZ Tecnivel manufactures batteries with pipes of all commonly used diameters (3/8 ”, 1/2” and 5/8 ”), as well as a wide range of construction variants, in terms of materials and designs. In sizes from 200mm to 6000mm fin length.
The coils or exchangers are designed for the exchange of fluids on the tube side and air on the fin side, and are used for the cooling or heating of liquids, vapor condensation, direct expansion or pumping of refrigerants and their condensation to any type of application in the wide world of refrigeration and air conditioning.
Not only are they incorporated into the equipment we manufacture in our production plant, but also, upon request, they are made to measure, to be incorporated into any type of air conditioning unit or application that they require.
Maximum reliability and quality assured thanks to the fact that all coils pass the strictest quality controls by means of a hydrostatic leak test.
Product Overview
Whether for our units or for air treatment plants, industrial processes from other manufacturers, we ensure reliability, quality and reduced delivery times.
- Wide range of construction possibilities:
- Pipes Cu and Fins Al
- Pipes Cu and Fins Cu
- Pipes Cu and laquered Fins
- Pipes Fe and Fins Al
- Pipes Fe stainless and Fins Al
- Pipes Fe stainless and Fins Al stainless.
- Pipes smooth or grooved interior
- For all types of thermal agents:
- Cold Water
- Hot Water
- Superheated water
- Steam
- Direct Expansion
- Evaporators
- Condensers
- Glycol water
- Pipes:
- 5/8"
- 1/2"
- 3/8"
- 7 mm
- Al / Coated fins
- Al or Cu fins fins
- Dimensions
- Widths from 200 to 2600 mm.
- Lengths from 300 to 6000 mm.
| Description / Materials | Exchangers with finned tube. Cold water and hot water coils, condensers, DX and steam. All coils are tested at 10 bar (air-water coils), and 30 bar (air-refrigerant coils), except the air-refrigerant R-410A coils, which are tested at 42 bar.Standard Cu tubes. Possible in Fe or stainless steel. Al fins, coated Al, Cu Galvanized frames, stainless steel or aluminium Manifolds with steel or copper tubes, depending on model. |
| Coils | Tubes 5/8", 1/2", 3/8"", 7 mm and Al / Coated Al or Cu fins fins |
| Dimensions | Widths ranging from 200 to 2600 mm. Lengths ranging from 300 to 6000 mm |
| Sizes / Models | Tailor-made for each project / design / diseño |
| Software | Selected and designed in our technical department, using our own market software. |
| Manufacture | Short delivery times thanks to our in-house production. Reliable units thanks to our exhaustive raw material selection process and because all our coils are subjected to the more stringent quality controls, with hydrostatic leak testing. |
